FEATURES

• Supports AMD® Ryzen™ 1st and 2nd Generation / Ryzen™ with Radeon™ Vega Graphics Processors and AMD® A-series / Athlon™ Processors for Socket AM4
• Support DDR4 1866/2133/2400/2667/2933(OC)/3200(OC) Mhz
• DDR4 Boost: Give your DDR4 memory a performance boost
• VR Ready: Best virtual reality game experience without latency
• Audio Boost: Reward your ears with studio grade sound quality for a HI-FI experience
• EZ Debug LED: Easiest way to troubleshoot
• X-Boost: Great tool to boost your USB & Storage performance
• Military Class 4, Guard-Pro: Latest evolution in high quality components for best protection and efficiency
• Click BIOS 5: Award-winning BIOS with high resolution scalable font, favorites and search function
• WHQL certified for Windows 10

​

COOLING

STAY COOL
Cooling your PC is essential for reliable performance. We've made sure to include enough fan headers with full control to allow you to cool your system to the max.

HDMI

Intel, the Intel Logo, Intel Inside, Intel Core, and Core Inside are trademarks of Intel Corporation or its subsidiaries in the U.S. and/or other countries.© 2018 NVIDIA Corporation. All rights reserved. NVIDIA, GeForce , and NVIDIA Pascal are registered trademarks of NVIDIA Corporation in the U.S and other countriesBrand and product names mentioned are trademarks of their respective owners.

All images and descriptions are for illustrative purposes only. Visual representation of the products may not be perfectly accurate. Product specification, functions and appearance may vary by models and differ from country to country . All specifications are subject to change without notice. Please consult the product specifications page for full details.Although we endeavor to present the most precise and comprehensive information at the time of publication, a small number of items may contain typography or photography errors. Products may not be available in all markets. We recommend you to check with your local supplier for exact offers.

SPECIFICATIONS

• SOCKET ： AM4
• CPU (MAX SUPPORT) ： RYZEN 7
• CHIPSET ： AMD® A320 Chipset
• DDR4 MEMORY ：  3220 Mhz
• MEMORY CHANNEL ： Dual
• DIMM SLOTS ： 2
• MAX MEMORY (GB) : 32
• PCI-E X16 :1
• PCI-E GEN ： Gen3
• PCI-E X1 ： 2
• SATAIII ： 4
• RAID ： 0/1/10
• TPM (HEADER) ： 1
• LAN ： 10/100/1000*1
• USB 3.1 PORTS (FRONT) ： 2(Gen1)
• USB 3.1 PORTS (REAR) ： 4(Gen1)
• USB 2.0 PORTS (FRONT) ： 4
• USB 2.0 PORTS (REAR) ： 2
• SERIAL PORTS(FRONT) ： 2
• AUDIO PORTS (REAR) ： Realtek® ALC887 Codec
• VGA ： 1
• DIRECTX ： 12
• FORM FACTOR ： M-ATX
• OPERATING SYSTEM ： Support for Windows® 10 64-bit / Support for Windows® 7 64-bit /* To support Windows® 7 64-bit, you must install an AMD Pinnacle Ridge & Summit Ridge CPU.
