Asus PRIME A520M-K AMD A520 Ryzen AM4 Micro ATX Motherboard With M.2 DDR4 D-Sub HDMI
| Price | RM328.00 RM399.00 RM |
| Product SKU | MOBO-ASUS-PRIME-A520M-K |
| Brand | MSI |
| Size (L x W x H) | 31 cm x 31 cm x 9 cm |
| Availability | Out Of Stock |
Description
Highlight
- AMD AM4 Socket : Ready For Ryzen™ 5000 Series/4000 G-Series/3000 Series Desktop Processors
- Comprehensive Cooling : PCH Heatsink And Fan Xpert
- Ultrafast Connectivity : M.2 Support, 1Gb Ethernet, USB 3.2 Gen 1 Type-A
- 5X Protection III : Multiple Hardware Safeguards For All-Around System Protection
Specification
| CPU | AMD AM4 Socket For AMD Ryzen™ 5000 Series/4000 G-Series/3000 Series Desktop Processors |
| Chipset | AMD A520 |
| Memory | 2 x DIMM, Max. 64GB, DDR4 4600(O.C)/4400(O.C)/4000(O.C.)/3866(O.C.)/3733(O.C.)/3600(O.C.)/3466(O.C.)/3333(O.C.)/3200/3000/2800/2666/2400/2133MHz Un-Buffered Memory Dual Channel Memory Architecture ECC Memory(ECC Mode) Support Varies By CPU |
| Graphic | 1 x D-Sub 1 x HDMI 2.1(4K@60HZ) |
| Expansion Slots | AMD Ryzen™ 5000 Series/4000 G-Series/3000 Series Desktop Processors 1 x PCIe 3.0 x16 (x16 Mode) AMD A520 Chipset 2 x PCIe 3.0 x1 |
| Storage | Total Supports 1 x M.2 Slot(s) And 4 x SATA 6Gb/s Ports AMD Ryzen™ 5000 Series/4000 G-Series/3000 Series Desktop Processors : 1 x M.2 Socket 3, With M Key, Type 2242/2260/2280(PCIE 3.0 x4 And SATA Modes) Storage Devices Support AMD A520 Chipset : 4 x SATA 6Gb/s Port(s), Support Raid 0, 1, 10 |
| LAN | Realtek RTL8111H 1Gb Ethernet Asus LANGuard |
| Audio | Realtek ALC887/897 7.1 Surround Sound High Definition Audio Codec Supports : Jack-Detection, Multi-Streaming, Front Panel Jack-Retasking, Up To 24-Bit/192kHz Playback Audio Feature : Audio Shielding Dedicated Audio PCB Layers |
| USB Ports | Rear USB Port(Total 6) 4 x USB 3.2 Gen 1 Port(s)(4 x Type-A) 2 x USB 2.0 Port(s)(2 x Type-A) Front USB Port(Total 6) 2 x USB 3.2 Gen 1 Port(s)(2 x Type-A) 4 x USB 2.0 Port(s)(4 x Type-A) |
| Software Features | Software Features Asus Exclusive Software Armoury Crate AI Suite 3 Performance And Power Saving Utility TurboV EVO EPU Digi+ VRM Fan Xpert EZ Update Asus CPU-Z AI Charger Daemon Tools Norton Anti-Virus Software(Free Trial For 60 Days) WinRAR UEFI BIOS Asus EZ DIY Asus CrashFree BIOS 3 Asus EZ Flash 3 Asus UEFI BIOS EZ Mode |
| ASUS Special Features | Asus 5X Protection III Asus DIGI+ VRM Asus LANGuard Asus Overvoltage Protection Asus SafeSlot Core Asus Stainless-Steel Back I/O Asus Q-Design Asus Q-DIMM Asus Q-Slot Asus Thermal Solution Aluminum Heatsink Design |
| Back I/O Ports | 1 x PS/2 Keyboard/Mouse Combo Port(s) 1 x D-Sub 1 x HDMI 1 x LAN(RJ45) Port(s) 4 x USB 3.2 Gen 1(Blue) Type-A 2 x USB 2.0 3 x Audio Jack(s) |
| Internal I/O Ports | 1 x CPU Fan Connector(s) 1 x Chassis Fan Connector(s) 1 x USB 3.2 Gen 1(Up To 5Gbps) Connector(s) Support(s) Additional 2 USB 3.2 Gen 1 Port(s) 2 x USB 2.0 Connector(s) Support(s) Additional 4 USB 2.0 Port(s) 1 x M.2 Socket 3 With M Key, Type 2242/2260/2280 Storage Devices Support (SATA & PCIE 3.0 x 4 Mode) 1 x SPI TPM Header 4 x SATA 6Gb/s Connector(s) 1 x S/PDIF Out Header(s) 1 x 24-Pin EATX Power Connector(s) 1 x 8-Pin EATX 12V Power Connectors 1 x Front Panel Audio Connector(s) (AAFP) 1 x Clear CMOS Jumper(s) 1 x System Panel Connector 1 x COM Port Header 1 x Speaker Connector |
| Accessories | User Manual I/O Shield 2 x SATA 6Gb/s Cable(s) 1 x Supporting DVD 1 x M.2 SSD Screw Package(s) |
| BIOS | 256MB Flash ROM, UEFI AMI BIOS |
| Manageability | WOL By PME, PXE |
| Operating System | Windows® 10 64-Bit |
| Form Factor | mATX Form Factor 8.9 Inch x 8.7 Inch (22.6cm x 22.1cm) |
What In The Box
- 1 x Asus PRIME A520M-K AMD A520 Ryzen AM4 Micro ATX Motherboard With M.2 DDR4 D-Sub HDMI
- 1 x I/O Shield
- 1 x M.2 SSD Screw
- 2 x SATA 6Gb/s Cable
- 1 x Supporting DVD
- 1 x User Manual
Warranty
3 Year Limited Warranty
Local Manufacturer Warranty
Warranty Policy : Please Complete And Submit Product Warranty Registration Form Within 14 Days Of Purchase To Ensure Continuous Coverage. Lazada Warranty Registration http://lwr.accessglobal.info Email Us At [email protected]
