Multiple Verification Methods
From fingerprint to card and password verification, R3 provides the possibilities. Optimize your security threshold, with fingerprint verification as your primary enrolment form.
Comprehensive Access Solution
Complement your R3 access control terminal with a R2c slave exit reader for a complete door-in and door out experience.
Data Management Simplified
R3 is equipped with TCP/IP connectivity and when that is not available, a USB flash drive is available to transfer transaction logs into your computer.
Precise Recognition with Biometrics
R3 utilizes minutiae matching technology that ensures only enrolled users are granted access, eradicating buddy punching scenarios.
High Definition Color Display and Touch Panel
Combining vibrance and function in a single stroke, our 2.4” color LCD and touch panel is bound to please in terms of aesthetics and function.
Enable Secure your premise with timezone features by R3, providing you total control in your access needs. R3 has TimeZone, GroupTimeZone and Group Verify features at your disposal.
Built In Alarm
R3 allows installation of external alarm to your access system to alert you during emergencies and break-ins. Secure your premise with GroupTimeZone and Group Verify functions.
Free Firmware and Software Updates
Functions and features are constantly evolving through technological research and industrial needs, hence our software and firmware updates for our devices come complimentary.
|SURFACE FINISHING||In-mould labelling (IML), poly carbonate (PC) &
acrylonitrile butadine systene (ABS)
|TYPE OF SCANNER||Optical fingerprint scanner|
|MEMORY||32MB SDRAM | 256MB Flash256 MB flash memory &
|ALGORITHM||BioBridge VX 10.0|
|DIMENSION (L X W X H), mm||78 x 32 x 190|
|• Fingerprint templates||3000|
|ENROLLMENT & VERIFICATION|
|• Methods||Fingerprint (1:1, 1:N), card or password|
|• Recommended Fingerprint per user ID||2|
|• Fingerprint placement||Any angle|
|• Verification time (sec)||< 1|
|• FAR (%)||< 0.001|
|• FRR (%)||< 1|
|• RFID: 64-bit, 125kHz, RF output power (EN300-330)||Yes|
|• MIFARE: MFIS50/S70, 13.56MHz||Made to order|
|• Method||TCP/IP, RS232, RS485, Flash disk|
|• Baud rates||9600, 19200, 38400, 57600, 115200|
|• Wiegand||26-bit input / output|
|• Temperature (°C)||0 ~ 45|
|• Humidity (%)||20 ~ 80|
|• Power input||DC 12V 3A|
|• Siren||Yes (relay output)|
|• Work codes||Yes|
|• Greeting Voice||Yes|
|• Display||2.4” 3k color LCD|
|• Short messaging||Yes|
|• EM-Lock Driving Output||12VDC/Relay output|
|• Alarm output||Yes (NO & NC)|
|VOICE / DISPLAY LANGUAGE (TERMINAL)||English (Standard), Arabic, Indonesian, Chinese Traditional / Simplified, Cantonese, Vietnamese, Spanish, Portuguese (Portugal), Turkish, Persian.
Other languages are available upon request.
