| Price | RM539.00 RM699.00 RM |
| Product SKU | ROU-MI-AX3600 |
| Brand | OEM |
| Size (L x W x H) | 47 cm x 34 cm x 11 cm |
| Availability | 1 |
| Quantity |
|
- 3Gigabit speed.
- Qualcomm IPQ8071A chip with 512MB of RAM and 256MB of storage together with OFDMA + MU-MIMO.
- Surrounded by six-high performance external signal amplifiers and a dedicated AIoT smart antenna.
- Support for the new WPA3 network encryption protocol.
Note:
*The product images on the above pages are for illustration purposes only; the physical product effects may vary slightly depending on the physical product.
*The data on the above pages are derived from the Xiaomi Laboratory, and were obtained in specific test environments. Actual use may vary slightly depending on the individual product, software version, conditions of use and environmental factors. Please refer to the actual use.
*The content and features shown on the above pages cannot be guaranteed to provide permanent services and may change as a result of changes in copyright, commercial or technical conditions. In case of any change, please refer to the actual contents and features of the product.
Specification
Brand |
Mi AioT Router |
|
Model |
AX3600 |
|
Hardware configuration |
|
| Processor |
IPQ8071A 4-core A53 1.4 GHz CPU |
| Network processing unit |
Dual-core 1.7 GHz NPU |
| ROM |
256MB |
| Memory |
512MB |
| 2.4G Wi-Fi |
2 × 2 (supports up to IEEE 802.11ax protocol, theoretical maximum speed of 574 Mbps) |
| 5G Wi-Fi |
4 × 4 (supports up to IEEE 802.11ax protocol, theoretical maximum speed of 2402 Mbps) |
| Product antenna |
6 external high-gain antennas + 1 external AIoT antenna |
| Product heat dissipation |
Natural heat dissipation |
| Total ports |
1× 10/100/1000M self-adaptive WAN port (Auto MDI/MDIX)3× 10/100/1000M self-adaptive LAN ports (Auto MDI/MDIX) |
| LED indicator light |
7× (SYSTEM light ×1, INTERNET light ×1, LAN light ×4, AIoT status light ×1) |
| System reset button |
1× |
| Power input port |
1× |
| Protocol standards |
IEEE 802.11a/b/g/n/ac/ax, IEEE 802.3/3u/3ab |
|
Wireless specifications |
|
| Dual band |
2.4GHz and 5GHz |
| Modulation |
11b: DSSS: DBPSK(1 Mbps), DQPSK (2 Mbps), CCK(5.5/11 Mbps) |
|
Software specifications |
|
| Operating system |
Mi Wi-Fi ROM intelligent router operating system based on a highly customized version of OpenWRT |
| Wireless security |
WPA-PSK/WPA2-PSK/WPA3-SAE encryption, wireless access control (blacklist and whitelist), SSID hiding, smart unauthorized access prevention |
| Management applications |
Supports web, Android, iOS |
| Security |
Access control (blacklist, whitelist), guest network, DoS, SPI firewall, IP and MAC address binding, IP and MAC filtering |
|
Product accessories |
|
| User manual |
1× |
| Networking cable |
1× |
| Product power supply |
1× (12 V/2 A) |
|
Working Environment |
|
| Working environment |
Temperature: 0°C to 40°C |
| Operating humidity |
10%–90% RH (no condensation) |
| Storage temperature |
-40°C to +70°C |
| Storage humidity |
5%–90% RH (no condensation) |
| Package contents |
XiaoMi Mi AIoT AX3600 WiFi 6 Router |
What In The Box
- 1 x Xiaomi Mi AIoT Router AX3600 Wi-Fi 6 DVB4236CN (Black)
- 1 x User Manual
- 1 x Power cable
- 1 x Networking cable
Warranty
1 Month Limited Warranty
Local Manufacturer Warranty
- 1 x Xiaomi Mi AIoT Router AX3600 Wi-Fi 6 DVB4236CN (Black)
- 1 x User Manual
- 1 x Power cable
- 1 x Networking cable
