Camera

1/2.7" Progressive Scan CMOS

2560 × 1920

Color: 0.01 Lux @ (F2.0, AGC ON), B/W: 0 Lux with IR

1/3 s to 1/100,000 s

IR cut filter

Pan: 0° to 355°, tilt: 0° to 75°

Lens

Fixed focal lens, 2.8 and 4 mm optional

2.8 mm, horizontal FOV 98.0°, vertical FOV 71.7°, diagonal FOV 127.0°
4 mm, horizontal FOV 75.3°, vertical FOV 55.5°, diagonal FOV 98.2°

M12

Fixed

F2.0

Illuminator

IR

Up to 30 m

850 nm

Video

50 Hz: 20 fps (2560 × 1920)
25 fps (2560 × 1440, 1920 × 1080, 1280 × 720)
60 Hz: 20 fps (2560 × 1920)
30 fps (2560 × 1440, 1920 × 1080, 1280 × 720)

50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360)
60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360)

Main stream: H.265+/H.265/H.264+/H.264
Sub-stream: H.265/H.264/MJPEG

32 Kbps to 16 Mbps

Baseline Profile/Main Profile/High Profile

Main profile

1 fixed region for main stream

Network

TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP,
UPnP™, SMTP, IGMP, 802.1X, QoS, IPv6, Bonjour, IPv4, UDP, SSL/TLS

Up to 6 channels

Open Network Video Interface, ISAPI

Up to 32 users. 3 levels: administrator, operator and user
3 user levels: administrator, operator, and user

iVMS-4200, Hik-Connect

Plug-in required live view: IE 10+
Plug-in free live view: Chrome 57.0+, Firefox 52.0+
Local service: Chrome 57.0+, Firefox 52.0+


Saturation, brightness, contrast, sharpness, AGC, white balance adjustable by client software or web browser

Auto, Schedule, Day, Night

120 dB

BLC, 3D DNR

Interface

1 RJ45 10 M/100 M self-adaptive Ethernet port

Event

Motion detection, video tampering, exception

Upload to FTP, notify surveillance center, send email

General

12 VDC ± 25%, 0.4 A, max. 5 W, Ø5.5 mm coaxial power plug
PoE: 802.3af, Class 3, 36 V to 57 V, 0.2 A to 0.15 A, max. 6.5 W

Ø110.8 mm × 84.7 mm (4.4" × 3.3")

134 mm × 134 mm × 108 mm (5.3" × 5.3" × 4.3")

Approx. 520 g (1.1 lb.)

Approx. 720 g (1.6 lb.)

-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)

-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)

English, Ukrainian

Anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter

Approval

FCC SDoC: 47 CFR Part 15, Subpart B;
CE-EMC: EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3:2013+A1:2019, EN 50130-4: 2011+A1: 2014;
RCM: AS/NZS CISPR 32: 2015;
IC VoC: ICES-003: Issue 7;
KC: KN 32: 2015, KN 35: 2015

UL: UL 62368-1;
CB: IEC 62368-1:2014+A11;
CE-LVD: EN 62368-1:2014/A11:2017;
BIS: IS 13252(Part 1):2010/ IEC 60950-1: 2005

CE-RoHS: 2011/65/EU;
WEEE: 2012/19/EU;
Reach: Regulation (EC) No 1907/2006

IP67: IEC 60529-2013, IK10: IEC 62262:2002
