Specifications

• Model : CS-H8c-R100-1K3KF4GA
• Image Sensor : 1/2.8" Progressive Scan CMOS
• Shutter Speed ： Self-adaptive shutter
• Lens ： 4mm@ F1.6, viewing angle: 46° (Vertical), 86° (Horizontal), 102° (Diagonal) 6mm@ F1.6, viewing angle: 28° (Vertical), 52° (Horizontal), 62° (Diagonal)
• PT Angle ： Pan: 350°, Tilt: 80°
• Minimum Illumination ： 0.5 Lux @(F1.6, AGC ON), 0 Lux with IR (*data is obtained from EZVIZ laboratories)
• Lens Mount ： M12
• DNR ： 3D DNR
• WDR ： Digital WDR
• Black & White Night ： 30m / 98ft

Video & Audio

• Max Resolution ： 2304 × 1296
• Frame Rate ： Max:30fps; Self-Adaptive during network transmission
• Video Compression ： H.265 / H.264
• H.265 Type ： Main Profile
• Video Bit Rate ： Ultra-HD; Hi-Def; Standard. Adaptive bit rate.
• Audio Bit Rate ： Self-Adaptive
• Max. Bitrate ： 3 Mbps

Network

• Frequency Bands ： IN LTE-FDD：B1/B3/B5/B8 IN LTE-TDD：B34/B38/B39/B40/B41 EU LTE-FDD：B1/B3/B5/B7/B8/B20/B28 LA LTE-FDD：B2/B3/B4/B5/B7/B8/B28/B66
• Wired Network ： RJ45 × 1 (10M / 100M Adaptive Ethernet Port)

Functions

• Smart Alarm ： Human Motion Detection,Vehicle Detection
• Auto Tracking ： Supports
• Customized Alert Area ： Supports
• Two-way Talk ： Supports
• Preset Locations ： Supports
• General Function ： Anti-Flicker, Dual-Stream, Heart Beat, Password Protection, Watermark

Storage

• Local Storage ： Supports microSD Card (Up to 512 GB)
• Cloud Storage ： Supports EZVIZ CloudPlay storage (Subscription required)

General

• Operating Conditions ： -30°C to 50°C ( -22 °F to 122 °F ) Humidity 95% or less (non-condensing)
• IP Grade ： Weatherproof Design
• Power Supply ： DC 12V/1A
• Dimensions ： 100 × 136 × 140mm (3.94 × 5.35 × 5.51 inch)
• Packaging Dimensions ： 140 × 140 × 192mm (5.51 × 5.51 × 7.56 inch)
• Weight ： Net Weight: 513.8 g (18.12 oz) With Package: 796.7 g (28.1 oz) For EU Standard Version

Certifications

• Certifications ： CE / WEEE / RoHS / REACH

What In The Box

• 1 x EZVIZ H8C 4G 2K 3MP 4MM PAN & TILT AI Human/Vehicle Shape Detection Smart Auto-Tracking 4G Camera
• 1 x Drill Template
• 1 x Screw Kit
• 1 x Waterproof Kit
• 1 x Power Adapter
• 1 x Regulatory Information
• 1 x Quick Start Guide

Warranty

2 Years Warranty

Local Manufacturer Warranty
