| Price | RM1,099.00 RM1,299.00 RM |
| Product SKU | NVR-TL-VIGI-NVR2008H-8MP |
| Brand | TP-Link |
| Size (L x W x H) | 45 cm x 30 cm x 20 cm |
| Availability | 2 |
| Quantity |
|
Description
Highlight
- 8-Channel Live View and 4K HDMI Video Output
- 8× 10/100 Mbps PoE+ Ports with 93 W PoE Budget
- 4-ch @ 4MP/ 8-ch @ 2MP Decoding Capability
- 8-Channel Synchronous Playback
- 80 Mbps Incoming Bandwidth and 60 Mbps Outgoing Bandwidth
- 2× SATA Interfaces and 1 Up to 16 TB
- H.265+ Compression Technology
- HDMI and VGA Simultaneous Output
- Remote Monitoring
Specifications
VIDEO AND AUDIO
| IP Video Input | 8-Channel |
| Incoming Bandwidth | 80 Mbps |
| Outgoing Bandwidth | 60 Mbps |
| HDMI Output Resolution | 1 Channel, Resolution: 3840x2160/30Hz, 1920x1080/60Hz, 1680x1050/60Hz, 1440x900/60Hz, 1280x1024/60Hz, 1280x720/60Hz |
| VGA Output Resolution | 1 Channel, Resolution: 1920x1080/60Hz, 1680x1050/60Hz, 1440x900/60Hz, 1280x1024/60Hz, 1280x720/60Hz |
| Video Output Mode | HDMI/VGA Simultaneous Output |
| Multi-View Display | 1/4/6/8 |
DECODING
| Audio Compression | G.711A/G.711U/G.726 |
| Video Compression | H.265+/H.265/ H.264+/H.264 |
| Record Resolution | 8MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
| Synchronous Playback | 8-Channel |
| Capability |
|
| Record Mode |
|
| Playback Mode |
|
| Backup Mode |
|
| Playback Function |
|
| Protocol | UPnP (Plug and Play), NTP (Network Timing), SMTP, DNS, TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, RTSP, SSL/TLS, RTP, IPv4, ARP |
| Mobile Phone Access | Android, iOS |
| Web Browser | Chrome (57+), Firefox (52+), Edge (91+) |
| Interoperability | ONVIF, CGI |
| Network Interface | 1, RJ-45 10/100 Mbps Self-Adaptive Ethernet Interface |
| USB Interface | 1 Front USB 2.0 Port, 1 Rear USB 2.0 Port |
| Audio Interface | 1-ch RCA Input; 1-ch RCA Output |
| Alarm In/Out | N/A |
| Serial Interface | N/A |
| Power | 1× DC Jack |
| Reset Button | 1 |
| Speaker | N/A |
| eSATA | 1 |
| HDMI | 1 |
| VGA | 1 |
| SATA | 2 SATA Interfaces |
| Capacity | Up to 16 TB Capacity for Each HDD* |
| Standard | 802.3at/af Compliant |
| Interface | 1-8, RJ-45 10/100 Mbps Self-Adaptive Ethernet Interface |
| PoE Budget | 93 W△ Available for All PoE+ Ports, 30 W Max per Port |
| General Alarm |
|
| Anomaly Alarm |
|
| Alarm Linkage |
|
| Storage Temperature | -40–70 °C |
| Storage Humidity | 10%~90% RH Non-Condensing |
| Package Contents |
|
| Working Temperature |
|
| Working Humidity | 10%~90% RH Non-Condensing |
| Dimensions( W X D X H ) | 330 × 285 × 45 mm |
| Net Weight | 2.1 Kg |
| Gross Weight | 4.1 Kg |
| Power Supply | 53.5V DC/2.43A |
| Power Consumption |
|
| Certifications | CE, EAC, UKCA, RCM, Triman, BSMI, VCCI, FCC, IC, HDMI |
What's in the box
- 1 x VIGI Network Video Recorder
- 1 x Power Adapter
- 1 x Power Cables
- 1 x HDD Power Cables
- 1 x HDD Data Cables
- 1 x Mounting Accessories
- 1 x Mouse
- 1 x Quick Installation Guide
Warranty
2 Years Warranty
Local Manufacturer Warranty
