| Price | RM372.00 RM405.00 RM |
| Product SKU | NVR-UNV-XVR301-08Q |
| Brand | Uniview |
| Size (L x W x H) | 35 cm x 40 cm x 24 cm |
| Availability | 1 |
| Quantity |
|
- Support H.265/H.264 video formats
- Support audio over coaxial cable
- Support TVI, AHD, CVI, CVBS, IP cameras with adaptive access
- 4/8-channel BNC input
- Support 1-ch HDMI output, 1-ch VGA output at up to 1920*1080
- Long transmission distance over coaxial cable
Features
- Support H.265/H.264 video formats
- Support audio over coaxial cable
- Support TVI, AHD, CVI, CVBS, IP cameras with adaptive access
- 4/8-channel BNC input
- Support 1-ch HDMI output, 1-ch VGA output at up to 1920*1080
- Long transmission distance over coaxial cable
- The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries
Specifications
|
Model |
XVR301-08Q | ||||
|
Video/Audio Input |
|||||
|
Analog Video Input |
8-ch, BNC | ||||
|
IP Video Input |
4-ch(only IP up to 12ch), each channel up to 4K | ||||
| Supported Analog Camera Types | Support AHD input: 8MP@15fps 5MP@20fps 4MP@30fps 3MP@30fps(channel1-channel2) 1080P@30fps 720P@60fps Support TVI input: 8MP@15fps 5MP@20fps 4MP@30fps 3MP@20fps(channel1-channel2) 1080P@30fps 720P@60fps Support CVI input: 8MP@15fps 5MP@20fps 4MP@30fps 1080P@30fps 720P@30fps Support CVBS input |
||||
|
Audio Input |
1-ch, RCA | ||||
|
Two-way Audio |
1-ch, RCA | ||||
|
Network |
|||||
|
Incoming Bandwidth |
56Mbps | ||||
|
Outgoing Bandwidth |
64Mbps | ||||
|
Remote Users |
128 | ||||
|
Protocols |
TCP/IP, P2P, UPnP, NTP, DHCP, PPPoE | ||||
|
Video/Audio Output |
|||||
|
CVBS Output |
1-ch, BNC | ||||
|
VGA Output |
1920x1080p/60Hz, 1920x1080p/50Hz, 1600x1200/60Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz | ||||
|
HDMI Output |
3840 x 2160/30Hz, 1920x1080p/60Hz, 1920x1080p/50Hz, 1600x1200/60Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz | ||||
|
Audio Output |
1-ch, RCA | ||||
|
Synchronous Playback |
8-ch | ||||
|
Encoding |
|||||
|
Recording Resolution |
8MP Lite/5MP Lite/4MP Lite /1080P/960P/720P/960H/D1/4CIF/CIF | ||||
|
Recording Frame Rate |
Main stream: 8MP Lite@8fps 5MP Lite@12fps 4MP Lite@15fps 3MP@15fps(channel1-channel2) 1080P@15fps 720P@30fps Sub stream: D1@12fps(Max) |
||||
|
Hard Disk |
|||||
|
SATA |
1 SATA interface | ||||
|
Capacity |
Up to 8TB for each disk (The maximum HDD capacity varies with environment temperature) |
||||
|
Smart |
|||||
|
VCA Detection |
2-ch Intrusion detection and cross line detection on analog camera | ||||
|
VCA Search |
Behavior search on analog camera | ||||
|
External Interface |
|||||
|
Network Interface |
1 RJ45 10M/100M self-adaptive Ethernet Interface | ||||
|
USB Interface |
Rear panel: 2 x USB2.0 | ||||
|
Serial Interface |
1 x RS485 | ||||
|
General |
|||||
| Power Supply | 12V DC Power Consumption: ≤ 8 W( without HDD ) |
||||
|
Working Environment |
-10°C ~ + 55°C ( +14°F ~ +131°F ), Humidity ≤ 90% RH(non-condensing) | ||||
|
Dimensions(W×D×H) |
260mm ×240mm× 46mm (10.2" × 9.4"×1.8") | ||||
|
Weight ( without HDD ) |
≤1.1 Kg ( 2.42lb ) | ||||
What's in the box
- 1 x Uniview XVR301-08Q 8CH 4K H.265 Network Video Recorder
- 1 x Power Adapter
- 1 x Mouse
- 1 x Screw
- 1 x Hard Disk Data Cable
- 1 x Hard Disk Power Cable
Warranty
3 Year Limited Warranty
Local Manufacturer Warranty
