| Price | RM476.00 RM519.00 RM |
| Product SKU | NVR-UNV-XVR301-16G |
| Brand | Uniview |
| Size (L x W x H) | 35 cm x 40 cm x 24 cm |
| Availability | 1 |
| Quantity |
|
- Support H.265/H.264 video formats
- Support audio over coaxial cable
- Support TVI, AHD, CVI, CVBS, IP cameras with adaptive access
- 16-channel BNC input
- Support 1-ch HDMI output, 1-ch VGA output at up to 1920*1080
- Long transmission distance over coaxial cable
- The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries.
Specification
|
Model |
XVR301-16G | |
|
Video/Audio Input |
||
|
Analog Video Input |
16-ch, BNC | |
|
IP Video Input |
8-ch(only IP up to 16ch), each channel up to 8MP | |
| Supported Analog Camera Types | Support AHD input: 5MP@12fps 4MP@15fps 1080P@30fps 720P@30fps Support TVI input: 5MP@12fps 4MP@15fps 1080P@30fps 720P@30fps Support CVI input: 1080P@30fps 720P@30fps Support CVBS input |
|
|
Audio Input |
1-ch, RCA | |
|
Network |
||
|
Incoming Bandwidth |
40Mbps (up to 56Mbps after all analog camera conversion) | |
|
Outgoing Bandwidth |
64Mbps | |
|
Remote Users |
128 | |
|
Protocols |
TCP/IP, P2P, UPnP, NTP, DHCP, PPPoE | |
|
Video/Audio Output |
||
|
VGA Output |
1920x1080/60Hz, 1920x1080/50Hz, 1600x1200/60Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz | |
|
HDMI Output |
1920x1080/60Hz, 1920x1080/50Hz, 1600x1200/60Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz | |
|
Audio Output |
1-ch, RCA | |
|
Two-way Audio |
1-ch, RCA | |
|
Synchronous Playback |
16-ch | |
|
Encoding |
||
|
Recording Resolution |
5MP Lite/4MP Lite /1080P/1080P Lite/720P/D1/CIF | |
| Recording Frame Rate |
Main stream: |
Sub stream: |
|
5MP Lite@6fps |
D1@6fps | |
|
4MP Lite@8fps |
D1@8fps | |
|
1080P Lite@15fps |
D1@6fps | |
|
720P@15fps |
D1@10fps | |
|
Hard Disk |
||
|
SATA |
1 SATA interface | |
|
Capacity |
Up to 8TB for each disk (The maximum HDD capacity varies with environment temperature) |
|
|
External Interface |
||
|
Network Interface |
1 RJ45 10M/100M self-adaptive Ethernet Interface | |
|
USB Interface |
Rear panel: 2 x USB2.0 | |
|
Serial Interface |
1 x RS485 | |
|
General |
||
|
Power Supply |
12V DC Power Consumption: ≤ 10 W( without HDD ) |
|
|
Working Environment |
-10°C ~ + 55°C ( +14°F ~ +131°F ), Humidity ≤ 90% RH(non-condensing) | |
|
Dimensions(W×D×H) |
260mm ×240mm× 46mm (10.2" × 9.4"×1.8") | |
|
Weight ( without HDD ) |
≤1.1 Kg ( 2.42lb ) | |
What In The Box
- 1 x UNIVIEW XVR301-16G 16CH 8MP H.265 NETORK VIDEO RECORDER
- 1 x Power Adapter
- 1 x Mouse
- 1 x Screw
- 1 x Hard Disk Data Cable
- 1 x Hard Disk Power Cable
Warranty
1 Year Limited Warranty
Local Manufacturer Warranty
- 1 x UNIVIEW XVR301-16G 16CH 8MP H.265 Network Video Recorder
- 1 x Power Adapter
- 1 x Mouse
- 1 x Screw
- 1 x Hard Disk Data Cable
- 1 x Hard Disk Power Cable
